• 12.2 MP CMOS sensor
• 3.5fps
• Suitable Memory Card Size: 8GB CF
• EOS Integrated Cleaning System
• 3.0" LCD with Live View mode
• DIGIC III processor
• Large, bright viewfinder
• Total image control
• Compact and lightweight
• Compatible with EF/EF-S lenses and EX Speedlites

Image Censor

• Type: 22.2 x 14.8mm CMOS
• Effective Pixels: Approx. 12.2M
• Total Pixels: Approx. 12.2M
• Aspect Ratio: 3:2
• Low-Pass Filter: Built-in/Fixed with Self Cleaning Sensor Unit
• Colour Filter Type: Primary Colour

Image Processor

• Type: DIGIC III

Lens

• Lens Mount: EF/EF-S
• Focal Length: 1.6x Multiplication with EF lens fitted

Focusing

• Type: TTL-CT-SIR with a CMOS sensor
• AF System / Points: 9 AF points (Cross type f/2.8 at centre)
• AF Working Range: EV -0.5 -18 (at 23C & ISO100)
• AF Modes:
• AI Focus
• One Shot
• AI Servo
• AF Point selection: Automatic selection, Manual selection
• Selected AF Point Display: Superimposed in viewfinder and indicated on LCD monitor
• Predictive AF: Yes
• AF Lock: Locked when shutter button is pressed half way in One Shot AF mode
• AF Assist Beam: Intermittent firing of built-in flash
• Manual Focus: Selected on lens

Exposure ControlMetering Modes:

• TTL full aperture metering with 35-zone SPC
• (1) Evaluative metering (linked to all AF points)
• (2) Partial metering at center (approx. 9% of viewfinder)
• (3) Spot metering at center (approx. 4% of viewfinder)
• (4) Center weighted average metering
• Metering Range: EV 1-20 (at 23C with 50mm f/1.4 lens ISO100)

AE Lock:

• Auto: Operates in 1-shot AF mode with evaluative metering when focus is achieved
• Manual: By AE lock button in creative zone modes
• Exposure Compensation: /- 3 EV, 1/2 or 1/3-stop increments
• AEB: /- 3 EV, 1/2 or 1/3-stop increments
• ISO Speed Equivalent: AUTO(100-800), 100, 200, 400, 800, 1600 (in 1/3-stop increments)
• ISO 200-1600 in Highlight Tone Priority (C.Fn II -3)

Shutter

• Type: Electronically-controlled focal-plane shutter
• Speed: 30-1/4000 sec (1/2 or 1/3 stop increments), Bulb
• Shutter Release: Soft touch electromagnetic release

White Balance

• Type: Auto white balance with the imaging sensor
• Settings: AWB, Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom.
• White balance compensation:

Physical Specifications

• Dimensions: 128.8 x 97.5 x 61.9 mm
• Weight (body only): Approx. 475g
