Specifications Overview

• 22.3 Megapixel CMOS Sensor:
  • High-resolution sensor ensuring detailed images.
  • Superior control over depth of field for creative photography.
  • Exceptional performance in various lighting conditions.
  • Rapid shooting capabilities.
  • Enhanced low-light photography.
  • High-quality 1080p video recording.
  • DIGIC 5 image processing for speed and image quality.
  • Large, bright display for easy viewing and navigation.
  • Efficient image backup options.
  • High Dynamic Range (HDR) mode for balanced exposures.
  • Broad range of compatible lenses.

Detailed Specifications

Image Sensor:

• Type: 36 x 24 mm CMOS
• Effective Pixels: Approximately 22.3 megapixels
• Total Pixels: Approximately 23.4 megapixels
• Aspect Ratio: 3:2
• Low-Pass Filter: Fixed, with fluorine coating
• Cleaning: EOS integrated system
• Color Filter: Primary Color

Image Processor:

• Type: DIGIC 5

Lens:

• Mount: EF mount (excluding EF-S lenses)
• Focal Length: Equivalent to lens' actual focal length

Focusing:

• Type: TTL-CT-SIR with dedicated CMOS sensor
• AF System/Points: 61-point (41 cross-type, 5 dual cross at f/2.8)
• Working Range: EV -2 - 18
• Modes: AI Focus, One Shot, AI Servo
• Point Selection: Various options including single point, zone, and 61-point selection
• AF Point Display: In viewfinder and LCD
• Lock: Half-press shutter or AF-ON button
• Assist Beam: Optional Speedlite
• Manual Focus: Via lens or Live View Mode
• Microadjustment: Customizable for multiple lenses

Exposure Control:

• Metering Modes: 63-zone dual layer SPC
• Brightness Range: EV 1 - 20
• AE Lock: Auto or manual
• Compensation: /-5 EV
• Bracketing: 2, 3, 5, or 7 shots; /-3 EV
• ISO Sensitivity: Expandable to 50, 51,200, 102,400

Shutter:

• Type: Electronically-controlled focal-plane
• Speed: 30-1/8000 sec Bulb

White Balance:

• Type: Auto with imaging sensor
• Settings: Various, including custom and bracketing

Viewfinder:

• Type: Pentaprism
• Coverage: Approx. 100%
• Magnification: Approx. 0.71x
• Dioptre Adjustment: -3 to 1 m-1
• Information Display: Comprehensive data display
• Depth of Field Preview: Yes

LCD Monitor:

• Type: 3.2" Clear View II TFT, approx. 1040K dots
• Coverage: Approx. 100%
• Viewing Angle: Approx. 170
• Brightness Adjustment: 7 levels
• Display Options: Multiple, including histogram and dual axis level

File Type and EOS Movie:

• Still Image Type: JPEG, RAW, sRAW
• Movie Size: Various, up to 1920 x 1080
• Movie Length: Max 29min 59sec, max file size 4GB

Other Features and Accessories:

• Custom Functions: 13 with 47 settings
• LCD Panel: Illuminated
• Water/Dust Resistance: Yes
• Orientation Sensor: Yes
• Playback Zoom: 1.5x - 10x
• Erase Protection: Yes
• Menu Languages: 25
• Firmware Update: User-updatable

Interface and Power Source:

• Computer Interface: Hi-Speed USB
• Battery: Rechargeable Li-ion LP-E6

Physical Specifications:

• Materials: Magnesium Alloy
• Operating Environment: 0 40 C, up to 85% humidity
• Dimensions: 152 x 116.4 x 76.4mm
• Weight (Body Only): Approx. 950g
